25D amplifier
Equalizer 2 x 16-band PEQ/notch/shelving/asymmetric
Latency analog and digital inputs 0.3 ms
Delay setting 0.3 ms – 10 s
Configurations
A list of d&b loudspeakers supported by the 25D is included in the Release notes of the amplifier firmware
Function switches
d&b loudspeaker specific circuits
Frequency generator
Pink noise or Sine wave 10 Hz – 20 kHz
- Maximum output power 4 x 1800/900 W into 4/8 Ω
- Monitoring display, colour TFT touchscreen, 4.3″ / 480 x 272 pixel
- 12 configurable GPIOs (8x GPI, 4x GPO)
- Milan-enabled
Equalizer 2 x 16-band PEQ/notch/shelving/asymmetric
Latency analog and digital inputs 0.3 ms
Delay setting 0.3 ms – 10 s
Configurations
A list of d&b loudspeakers supported by the 25D is included in the Release notes of the amplifier firmware
Function switches
d&b loudspeaker specific circuits
Frequency generator
Pink noise or Sine wave 10 Hz – 20 kHz
