S31
- 48 x Input flex-channels Mono/Stereo (equivalent of 96 DSP channels)
- 46 busses: 16 x flexi-busses Mono/Stereo (equivalent of 32 DSP busses), Stereo Master (2), Solo busses (2 stereo, 4 total), and 10 x 8 Matrix (8)
- 10 x Control Groups
- 1 x Compressor per channel and buss
- 1 x Gate per channel and buss (switchable to ducker, or compressor with side chain access)
- 16 x assignable 32 band Graphic EQs
- 8 x FX engines (reverbs, delays, w/modulation and enhancer)
- 21 x assignable DiGiTuBes
- 21 x assignable Multiband Compressors
- 21 x assignable Dynamic EQ’s
- 24 mic/line inputs
- 12 analogue outs
- 2 AES/EBU I/O (mono)
- Word Clock I/O
- 1 GPI and 1 GPO
- DVI out (for an external monitor)
- 2 DMI Card slots (up to 64 I/O per slot)
- 2 Ethernet connections for Networking
- 2 x 24 segment master/solo meters
- Touch sensitive rotaries with integrated switch & HTL
- 3 x multi-touch screens
- 31 x touch sensitive moving faders
- 4 x layers of banks of 10 faders
- https://digico.biz/consoles/s31/
48 Flexi Input Channels (mono/stereo)
16 Flexi Aux / Sub-Group Busses (mono/stereo)
10 x 8 Matrix with full processing
Fully assignable channel layout
24 local mic/line inputs and 12 line outputs
2 DMI slots to expand the I/O as desired
- 48 x Input flex-channels Mono/Stereo (equivalent of 96 DSP channels)
- 46 busses: 16 x flexi-busses Mono/Stereo (equivalent of 32 DSP busses), Stereo Master (2), Solo busses (2 stereo, 4 total), and 10 x 8 Matrix (8)
- 10 x Control Groups
- 1 x Compressor per channel and buss
- 1 x Gate per channel and buss (switchable to ducker, or compressor with side chain access)
- 16 x assignable 32 band Graphic EQs
- 8 x FX engines (reverbs, delays, w/modulation and enhancer)
- 21 x assignable DiGiTuBes
- 21 x assignable Multiband Compressors
- 21 x assignable Dynamic EQ’s
- 24 mic/line inputs
- 12 analogue outs
- 2 AES/EBU I/O (mono)
- Word Clock I/O
- 1 GPI and 1 GPO
- DVI out (for an external monitor)
- 2 DMI Card slots (up to 64 I/O per slot)
- 2 Ethernet connections for Networking
- 2 x 24 segment master/solo meters
- Touch sensitive rotaries with integrated switch & HTL
- 3 x multi-touch screens
- 31 x touch sensitive moving faders
- 4 x layers of banks of 10 faders
- https://digico.biz/consoles/s31/
Sản phẩm tương tự
48 Flexi Input Channels (mono/stereo) 16 Flexi Aux / Sub-Group Busses (mono/stereo) 10 x 8 Matrix with full processing Fully assignable channel layout 24 local mic/line inputs and 12 line outputs 2 DMI slots to expand the I/O as desired
